Pressure transmitter PGT15IV
Pressure (0-10 V)
Technical data
| PGT15IV / Pressure | |
|---|---|
| Measuring range | -0.5 … 15.0 bar |
| Accuracy |
± 1.0% (0 … 50 °C) |
| Pressure connection |
G 7/16” UNF female thread with Schrader valve opener |
| Tube Ø | 17 x 58 mm |
| Electrical connection | mpm connector incl. cable socket, IP65 |
